Mercusys MB115-4G 300 Mbps Wireless N 4G LTE Router
The Mercusys MB115-4G is a 4G LTE router designed to share mobile internet with multiple devices quickly and easily. Simply insert a SIM card to create a fast, stable wireless network for home or small office use.
Key Features
-
4G Network Sharing
Share your 4G LTE internet connection with up to 32 Wi‑Fi devices. Enjoy download speeds of up to 150 Mbps (network dependent). -
Plug a SIM Card and Play
Just insert a SIM card to get online. No configuration is required. SIM card compatibility is supported by years of field testing.
Note: Make sure your SIM card is unlocked. -
300 Mbps Wireless N Wi‑Fi
Provides wireless speeds of up to 300 Mbps to share your network for everyday browsing and connectivity. -
Maximum Network Coverage
Four external antennas help provide stable and efficient wireless connections to every connected device. -
Flexible Wi‑Fi Router Mode
If 4G is not available, plug an Ethernet cable into the LAN/WAN port to use the device as a standard Wi‑Fi router.
Wireless
| Parameter | Details |
|---|---|
| Wireless Standards | IEEE 802.11b/g/n |
| Frequency | 2.4 GHz |
| Signal Rate | 300 Mbps |
| Reception Sensitivity | 11g 54M: -74.5 dBm 11n HT20 MCS7: -73.5 dBm 11n HT40 MCS7: -70.5 dBm |
| Transmission Power | \< 20 dBm (2.4 GHz) |
| Wireless Security | WPA-PSK / WPA2-PSK |
| Wireless Functions | Enable/Disable Wireless Radio, Wireless Schedule, WMM, Wireless Statistics |
Hardware
| Parameter | Details |
|---|---|
| Dimensions (W x D x H) | 219 x 140 x 32 mm (8.62 x 5.51 x 1.26 in) |
| Interfaces | 1 × 10/100 Mbps LAN/WAN Port 3 × 10/100 Mbps LAN Ports 1 × Nano SIM Card Slot |
| Buttons | WPS Reset Button |
| Ethernet Ports | 1 × 10/100 Mbps LAN/WAN Port 3 × 10/100 Mbps LAN Ports |
Network Type (EU)
| Technology | Bands (MHz) |
|---|---|
| FDD‑LTE | B1/B3/B5/B7/B8/B20/B28 (2100/1800/850/2600/900/800/700 MHz) |
| TDD‑LTE | B38/B40 (2600/2300 MHz) |
| HSPA+/UMTS | B1/B5/B8 (2100/850/900 MHz) |
Package Contents
- 300 Mbps Wireless N 4G LTE Router (MB115-4G)
- Power Adapter
- RJ45 Ethernet Cable
- Quick Installation Guide
Environment
| Condition | Range |
|---|---|
| Operating Temperature | 0°C ~ 40°C (32°F ~ 104°F) |
| Storage Temperature | -40°C ~ 60°C (-40°F ~ 140°F) |
| Operating Humidity | 10% ~ 90% Non‑Condensing |
| Storage Humidity | 5% ~ 90% Non‑Condensing |
