be quiet! Pure Base 501 LX Black – High-Airflow ARGB Mid-Tower ATX Case
The Pure Base 501 LX Black from be quiet! is a versatile ATX mid-tower PC case that combines compact dimensions with high airflow and striking ARGB lighting. Designed for performance-focused builds, it offers generous space for powerful components, flexible cooling options, and clean cable management.
Key Features
-
High-Airflow Design
High airflow intake front panel and top cover for maximum cooling performance. -
Premium ARGB Cooling Included
- 4 preinstalled Light Wings LX PWM fans for unmistakable lighting effects and strong air pressure
-
ARGB controller and ARGB-PWM hub for up to 6 fans
-
Versatile Hardware Support
- Generous space for high-end graphics cards and large CPU coolers despite a compact footprint
- Optional vertical graphics card installation
- Supports ATX, Micro-ATX, and Mini-ITX motherboards
-
Multiple storage options for HDDs and SSDs
-
Water-Cooling Ready
Supports radiators up to 360 mm for advanced liquid cooling setups. -
Clean Build & Presentation
- Comfortable cable management with clever cable routing design
- 25 mm of space behind the motherboard tray
- Tempered glass side panel to showcase your components
- Removable dust filters on the front, top, and bottom
Full Specifications
| Specification | Details |
|---|---|
| Model Number | BGW78 |
| Case Type | Mid-Tower |
| Dimensions (L x W x H) | 450 mm x 232 mm x 443 mm |
| Weight | 7.53 kg |
| Material | Steel, ABS plastic |
| Color | Black |
| Motherboard Support | ATX, Micro-ATX, Mini-ITX |
Storage & Expansion
| Component | Details |
|---|---|
| Drive Bays | 2 x 3.5" HDD, 5 x 2.5" SSD |
| Expansion Slots | 7 |
Cooling Support
| Position | Fan Support (mm) |
|---|---|
| Top | 2 x 140 / 2 x 120 |
| Front | 2 x 140 / 3 x 120 |
| Rear | 1 x 140 / 1 x 120 |
Radiator Support
| Position | Radiator Sizes (mm) |
|---|---|
| Top | 120 / 240 |
| Front | 120 / 140 / 240 / 280 / 360 |
| Rear | 120 / 140 |
Pre-Installed Fans
| Position | Fan Model |
|---|---|
| Front | 3 x Light Wings LX 120 mm PWM |
| Rear | 1 x Light Wings LX 140 mm PWM |
Front I/O Ports
| Port Type | Quantity |
|---|---|
| USB 3.2 Gen 2 Type-C | 1 |
| USB 3.2 Type-A | 2 |
| HD Audio I/O | 1 (Mic + Audio) |
Component Clearance & Other Features
| Feature | Details |
|---|---|
| Power Supply Support | ATX PS/2 |
| Maximum GPU Length | 369 mm |
| Maximum CPU Cooler Height | 190 mm |
| Cable Management Space | 25 mm behind motherboard tray |
| Dust Filters | Front, top, and bottom (removable) |
| Side Panel | Tempered glass |
