HCG1200 PRO Platinum ATX 3.1 Power Supply
For the Ultimate Gamer
The HCG1200 PRO Platinum ATX 3.1 is engineered for gamers and enthusiasts who demand premium quality, stability, and efficiency from their power supply. Featuring ATX 3.1 and PCIe 5.1 support, 100% high-quality JP capacitors, and 80 PLUS Platinum certification, it delivers exceptional performance for cutting-edge PC builds.
Key Features
ATX 3.1 & PCIe 5.1 Compatible
- Formally certified for ATX 3.1 compliance, meeting strict standards for reliability and power efficiency.
- Includes a PCIe 5.1 12VHPWR GPU cable for seamless compatibility with the latest graphics cards, such as NVIDIA GeForce RTX 40 Series.
100% High-Quality JP Capacitors
- Built with 100% high-quality JP capacitors.
- Achieves tight voltage regulation and minimal ripple and noise to maximize system performance.
PhaseWave™ Design
- Server-class full-bridge LLC design with synchronous rectification based on a DC-DC topology.
- Ensures highly efficient, stable power delivery.
CircuitShield™ Protection
- Full suite of industrial-grade protections:
- OCP, OVP, UVP, SCP, OPP, OTP, SIP, NLO
- Provides safe, reliable power in any situation.
Zero RPM Manager
- Thermal sensors activate the fan only when needed.
- Optimizes the balance between cooling performance and low noise.
- Zero RPM fan mode helps extend PSU lifespan and maintain quieter operation.
135mm FDB Silent Fan
- Whisper-quiet 135mm fluid-dynamic bearing (FDB) fan.
- Delivers high airflow with durability and longevity.
Full Modular Cable Management
- Fully modular design lets users connect only the cables they need.
- Reduces cable clutter, improves airflow, and provides a cleaner internal layout.
Compact Size
- Shorter length than typical high-end power supplies.
- Compatible with a wider range of PC cases.
10-Year Warranty
- Backed by a 10-year warranty from Antec, reflecting a strong commitment to long-term reliability.
Specifications
| Specification | Details |
|---|---|
| Model | HCG1200 PRO Platinum ATX3.1 |
| Type | ATX 12V 3.1 |
| Dimensions | 160(L) x 150(W) x 86(H) mm |
| Modular | Full-Modular |
| Warranty | 10 years |
| Input Voltage | 100V–240V |
| Input Current | 15A–7.5A |
| Input Frequency Range | 60Hz–50Hz |
| PFC | Active PFC |
| Power Good Signal | 100–150 ms |
| Protection | OCP, OVP, UVP, SCP, OPP, OTP, SIP, NLO |
| Output Capacity | 1200W |
| Operating Temperature | 0–40°C |
| Regulatory | cTUVus / TUV / CB / RCM / CE / FCC / BIS / BSMI / KC / UKCA / ICES / CCCF |
| Fan | 135mm FDB Silent Fan |
| Certifications | 80 PLUS Platinum |
Connectors
- 1 x 24(20+4) pin MB
- 1 x 16(12+4) pin PCIe 5.1 12VHPWR
- 2 x 8(4+4) pin CPU
- 3 x 8(6+2) pin PCI-E
- 14 x SATA
- 3 x Molex
The HCG1200 PRO Platinum ATX 3.1 is a powerful, efficient, and highly reliable choice for your next high-performance gaming or enthusiast PC build.
